RAW 4x4 Heavy-Duty Suspension Lift Kit – Ford Ranger T7 (2016–2019)

RAW 4x4 Heavy-Duty Suspension Lift Kit – Ford Ranger T7 (2016–2019)

RAW 4x4 Heavy-Duty Suspension Lift Kit – Ford Ranger T7 (2016–2019)

Fix your bakkie’s load handling and upgrade its trail performance with the commercial truck-tough RAW 4x4 Heavy-Duty Suspension Kit for the Ford Ranger T7 (2016–2019), covering mid-lifecycle facelift models including the 2.2 TDCi and 3.2 TDCi Duratorq variants across XL, XLT, and Wildtrak trims. Born from a legacy of heavy commercial vehicle engineering by Powerdown, this system corrects the notorious soft factory nose-dive and eliminates the floating unladen ride while providing up to 55mm of ground clearance within safe operating thresholds for the T7’s front CV axles.

Whether you’re packing a Quick Pitch Quick-en-Suite Box Unit or carrying full overlanding equipment, the upgraded front coils and R-RAN11B Constant-Load Leaf Springs stop dangerous rear-end sag dead in its tracks. Equipped with massive 45mm-bore Nitro Max shocks in a 61mm outer tube with multi-lip HNBR high-temperature seals, this kit completely eradicates dampening fade over hours of brutal corrugated gravel bush tracks.

Kit Components & Part Numbers

  • Front Nitro Max Struts – Pair (NM1474S) – 45mm bore, 61mm outer tube, multi-lip HNBR high-temperature seals
  • Front Raised Coil Springs (RC-1474) – 0–50kg / Comfort Touring
  • Front Heavy-Duty Raised Coil Springs (RC-1475) – 50–100kg / Steel Bumper & Winch — mandatory to eliminate nose-dive under heavy steel bumpers
  • Rear Nitro Max Shock Absorbers – Pair (NM9113M1) – matched rear damping for T7 platform
  • Rear Heavy-Duty Leaf Springs (R-RAN11A) – Medium load, 0–150kg constant
  • Rear Extra Heavy-Duty Leaf Springs (R-RAN11B) – Constant 300kg+ for RTT, canvas tents, canopies & drawers
  • Polyurethane Bush & U-Bolt Fitting Kit (RAW-BU-RAN11) – complete hardware included

Technical Specifications

  • Total Lift: 45mm – 55mm over factory ride height
  • Kit Weight: ~66–73kg (high-tensile multi-leaf rear packs)
  • Packaged Dimensions: 1,330mm × 460mm × 310mm
  • Shock Bore: 45mm | Outer Tube: 61mm steel | Sealing: Multi-lip HNBR high-temperature

Warranty

Industry-leading 3-Year / 60,000km Warranty — covers leaf sagging, coil fracturing, and high-pressure oil seal blowouts under heavy overlanding loads.

Professional Fitment Available Nationwide

Prefer to have it fitted by experts? Advanced 4x4 offers professional fitment at our fitment centres across South Africa. Simply place your order online and contact us to book your fitment appointment at the centre nearest to you. Our trained technicians will ensure your suspension kit is installed correctly for optimal performance and safety.

Selecting the Right Configuration

To ensure you receive the correct spring rate for your build, please specify your setup at checkout:

  • Front-end weight: Standard Bumper / Replacement Steel Bullbar & Winch
  • Rear-end setup: Light–Medium Loads (0–150kg) / Permanent 300kg+ Canopy, RTT & Camp Setup

Lead Time: Please allow 14 business days for production/sourcing if stock is not immediately available.
