RAW 4x4 Heavy-Duty Suspension Lift Kit – Isuzu D-Max / KB Series (2013–2022)

RAW 4x4 Heavy-Duty Suspension Lift Kit – Isuzu D-Max / KB Series (2013–2022)

Fix your bakkie’s load handling and upgrade its trail performance with the commercial truck-tough RAW 4x4 Heavy-Duty Suspension Kit for the Isuzu D-Max / KB Series (2013–2022), covering RT50 and RT85 platforms. Born from a legacy of heavy commercial vehicle engineering by Powerdown, this system eliminates the harsh unladen leaf chatter and severe tail sag of the stock bakkie while providing up to 50mm of ground clearance — carefully limited to preserve factory independent front CV axle boot geometry.

Whether you’re packing a Quick Pitch Quick-en-Suite Box Unit, an overlanding canopy setup, or heading cross-border on corrugated gravel routes, the upgraded front coils and R-ISU13B Constant-Load Leaf Springs stop rear-end sag dead in its tracks. Equipped with massive 45mm-bore Nitro Max shocks in a 60mm outer tube with high-pressure HNBR multi-lip dust and oil seals built to withstand harsh trail grit, this kit completely eradicates dampening fade over hours of brutal off-road driving.

Kit Components & Part Numbers

• Front Nitro Max Struts – Pair (NM1011S) – 45mm bore, 60mm outer tube, HNBR multi-lip seals; available as pre-assembled convenience units with top hats pre-fitted
• Front Raised Coil Springs (RC-1011) – 0–50kg / Comfort Touring
• Front Heavy-Duty Raised Coil Springs (RC-1012) – 50–100kg / Steel Bumper & Winch — mandatory to eliminate nose-dive under heavy steel bumpers
• Rear Nitro Max Shock Absorbers – Pair (NM2152M5) – matched rear damping
• Rear Heavy-Duty Leaf Springs (R-ISU13A) – Medium load, 0–150kg constant
• Rear Extra Heavy-Duty Leaf Springs (R-ISU13B) – Constant 300kg+ for RTT, canvas tents, canopies & drawers
• Polyurethane Bush & U-Bolt Fitting Kit (RAW-BU-ISU13) – complete hardware included

Technical Specifications

• Total Lift: 40mm – 50mm over factory ride height
• Kit Weight: ~64–70kg (commercial-grade multi-leaf rear packs)
• Packaged Dimensions: 1,320mm × 460mm × 290mm
• Shock Bore: 45mm | Outer Tube: 60mm steel | Sealing: HNBR multi-lip high-pressure dust & oil

Warranty

Industry-leading 3-Year / 60,000km Warranty — covers progressive leaf sagging, coil fracturing, and high-pressure oil seal blowouts under extreme trail conditions.

Professional Fitment Available Nationwide

Prefer to have it fitted by experts? Advanced 4x4 offers professional fitment at our fitment centres across South Africa. Simply place your order online and contact us to book your fitment appointment at the centre nearest to you. Our trained technicians will ensure your suspension kit is installed correctly for optimal performance and safety.

Selecting the Right Configuration

To ensure you receive the correct spring rate for your build, please specify your setup at checkout:

• Front-end weight: Standard Bumper / Replacement Steel Bullbar & Winch
• Rear-end setup: Light–Medium Loads (0–150kg) / Permanent 300kg+ Canopy, RTT & Camp Setup

⏳ Lead Time: Please allow 14 business days for production/sourcing if stock is not immediately available.
