RAW 4x4 Heavy-Duty Suspension Lift Kit – Isuzu MU-X Gen-1 (2013–2022)

RAW 4x4 Heavy-Duty Suspension Lift Kit – Isuzu MU-X Generation 1 (2013–2022)

Transform your SUV’s off-road load capacity and highway stability with the commercial truck-tough RAW 4x4 Heavy-Duty Suspension Kit for the Isuzu MU-X Generation 1 (2013–2022), built on the robust Isuzu KB / D-Max platform. Born from a rich pedigree of heavy commercial vehicle engineering by Powerdown, this system replaces soft, fatigued factory components to provide up to 45mm of ground clearance — carefully optimised to maintain safe velocity and angular thresholds for the front independent CV axles.

Unlike the bakkie variants, the Gen-1 MU-X utilizes an all-coil independent front and multi-link rear suspension layout — making this a lighter, more refined lift solution than leaf-spring bakkie kits. Whether you’re packing a Quick Pitch Quick-en-Suite Box Unit, an interior drawer system, or towing an off-road camper trailer, the upgraded front coils and RC-MUX13R-HD Constant-Load Rear Springs stop rear-end sag dead in its tracks. Equipped with massive-bore Nitro Max shocks with 35–45mm bore pistons in up to a 61mm outer tube and multi-lip HNBR high-temperature seals built to keep fine bush dust out.

Kit Components & Part Numbers

• Front Nitro Max Struts – Pair (NM1011S) – 35–45mm bore, up to 61mm outer tube, multi-lip HNBR seals; available as pre-assembled convenience units
• Front Raised Coil Springs (RC-1011) – 0–50kg / Comfort Touring
• Front Heavy-Duty Raised Coil Springs (RC-1012) – 50–100kg / Steel Bumper & Winch — mandatory to counteract heavy replacement steel bullbars
• Rear Nitro Max Shock Absorbers – Pair (NM2152M5) – matched rear damping for multi-link coil rear setup
• Rear Heavy-Duty Coil Springs (RC-MUX13R) – 0–150kg / Everyday Touring
• Rear Extra Heavy-Duty Coil Springs (RC-MUX13R-HD) – Constant 250kg+ for RTT, canvas tents, drawers & heavy camping setups

Technical Specifications

• Total Lift: 35mm – 45mm over factory ride height
• Kit Weight: ~31.5–35kg (all-coil setup — lighter than leaf-spring bakkie kits)
• Packaged Dimensions: 850mm × 450mm × 280mm
• Shock Bore: 35mm (Nitro) – 45mm (Nitro Max) | Outer Tube: up to 61mm steel | Sealing: Multi-lip HNBR high-temperature

Warranty

Industry-leading 3-Year / 60,000km Warranty — covers progressive coil sagging, manufacturing fracturing, and high-pressure oil seal blowouts under extreme cross-border overlanding loads.

Professional Fitment Available Nationwide

Prefer to have it fitted by experts? Advanced 4x4 offers professional fitment at our fitment centres across South Africa. Simply place your order online and contact us to book your fitment appointment at the centre nearest to you. Our trained technicians will ensure your suspension kit is installed correctly for optimal performance and safety.

Selecting the Right Configuration

The Gen-1 MU-X is widely used as a dual-purpose family holiday wagon and weekend tourer — spring rate selection matters significantly for ride comfort. Please specify your setup carefully at checkout:

• Front-end weight: Comfort Touring / Steel Bumper & Winch
• Rear-end setup: Comfort / Touring (0–150kg) / Permanent 250kg+ Overland Build or Heavy Towing (RTT, drawers, fridge & trailer)

⏳ Lead Time: Please allow 14 business days for production/sourcing if stock is not immediately available.
