RAW 4x4 Heavy-Duty Suspension Lift Kit – Jeep Wrangler JK (2007–2018)

RAW 4x4 Heavy-Duty Suspension Lift Kit – Jeep Wrangler JK (2007–2018)

Transform your trail machine’s load capacity and highway stability with the commercial truck-tough RAW 4x4 Heavy-Duty Suspension Kit for the Jeep Wrangler JK (2007–2018), covering all 2-door and 4-door Sport, Sahara, and Rubicon variants with 3.8L V6, 3.6L Pentastar, and 2.8L CRD engines. Born from a rich pedigree of heavy commercial vehicle engineering by Powerdown, this system replaces fatigued factory coils and shocks to provide up to 50mm of ground clearance — carefully engineered to prevent excessive wear on factory driveshaft boots and maintain correct tracking geometry.

The JK platform is famous for its front and rear quadra-coil solid-axle configuration, and this kit is purpose-built to eliminate the severe highway body sway and rear-end sag caused by permanent overland weights. Whether you’re packing a Quick Pitch Quick-en-Suite Box Unit, interior drawer systems, or heading cross-border on corrugated gravel routes, the upgraded coils and RC-JPJKR-HD Constant-Load Rear Springs stop rear-end sag dead in its tracks. Equipped with massive 41mm-bore Nitro Max shocks in a 60mm outer tube with high-pressure HNBR multi-lip dust and oil seals built to withstand harsh trail grit.

Kit Components & Part Numbers

• Front Nitro Max Shock Absorbers – Pair (M4134G) – 41mm bore, 60mm outer tube, HNBR multi-lip dust & oil seals
• Front Raised Coil Springs (RC-JPJKF) – 0–50kg / Standard Touring
• Front Heavy-Duty Raised Coil Springs (RC-JPJKF-HD) – 50–100kg / Steel Bar & Winch — mandatory to eliminate nose-dive under heavy steel bumpers
• Rear Nitro Max Shock Absorbers – Pair (M4135G) – matched rear damping for solid rear axle
• Rear Heavy-Duty Coil Springs (RC-JPJKR) – 0–150kg / Everyday Touring
• Rear Extra Heavy-Duty Coil Springs (RC-JPJKR-HD) – Constant 300kg+ for RTT, canvas tents & drawer slides
• Heavy-Duty Steering Damper Upgrade (RAW-SD-5011) – strongly recommended (see note below)

⚠️ Recommended Installation Accessories

The Jeep JK’s solid-front-axle layout means lifting the vehicle modifies the steering tracking angle. We strongly recommend adding the following to your order:

• Heavy-Duty Steering Stabilizer (RAW-SD-5011) – eliminates front-end bump-steer and high-speed wheel wobble on rough dirt tracks
• Adjustable Front Track Bar – re-centres the front axle to restore correct tracking geometry after lift installation

Technical Specifications

• Total Lift: 40mm – 50mm (1.5–2 inches) over factory ride height
• Kit Weight: ~33–37kg (all-coil setup — lighter than leaf-spring bakkie kits)
• Packaged Dimensions: 850mm × 450mm × 280mm
• Shock Bore: 41mm (Nitro Max) | Outer Tube: 60mm steel | Sealing: HNBR multi-lip high-pressure dust & oil

Warranty

Industry-leading 3-Year / 60,000km Warranty — covers progressive coil sagging, manufacturing fracturing, and high-pressure oil seal blowouts under extreme trail conditions.

Professional Fitment Available Nationwide

Prefer to have it fitted by experts? Advanced 4x4 offers professional fitment at our fitment centres across South Africa. Simply place your order online and contact us to book your fitment appointment at the centre nearest to you. Our trained technicians will ensure your suspension kit is installed correctly for optimal performance and safety.

Selecting the Right Configuration

To ensure you receive the correct setup for your build, please specify at checkout:

• Vehicle configuration: 2-Door / 4-Door (Unlimited)
• Front-end weight: Standard Touring / Steel Bar & Winch
• Rear-end setup: Everyday Touring (0–150kg) / Permanent 300kg+ Overland Build (RTT, drawers & camp gear)

⏳ Lead Time: Please allow 14 business days for production/sourcing if stock is not immediately available.
