RAW 4x4 Heavy-Duty Suspension Lift Kit – Jeep Gladiator JT (2020+)

RAW 4x4 Heavy-Duty Suspension Lift Kit – Jeep Gladiator JT (2020–Present)

Transform your truck’s load capacity and highway stability with the commercial truck-tough RAW 4x4 Heavy-Duty Suspension Kit for the Jeep Gladiator JT (2020+), covering all Sport, Overland, and extreme live-axle Rubicon variants. Born from a rich pedigree of heavy commercial vehicle engineering by Powerdown, this system replaces soft factory setups to provide 50mm of ground clearance — carefully calibrated to keep factory electronic stability modules, cross-axis joints, and driveshaft operating angles within safe parameters.

The Gladiator JT uniquely combines the solid-axle front end of the Wrangler with a lengthened five-link rear coil suspension derived from heavy truck platforms — purpose-engineered for serious cargo carrying. Whether you’re packing a Quick Pitch Quick-en-Suite Box Unit, an overlanding bed rack system, or heading cross-border on corrugated gravel routes, the upgraded coils and RC-JPJT20R-HD Constant-Load Rear Springs stop rear-end sag dead in its tracks. Equipped with massive 45mm-bore Nitro Max shocks in a 61mm outer tube with multi-lip HNBR high-temperature seals built to keep fine trail dust out.

Kit Components & Part Numbers

• Front Nitro Max Shock Absorbers – Pair (NM-JL19F) – 45mm bore, 61mm outer tube, multi-lip HNBR high-temperature seals
• Front Raised Coil Springs (RC-JPL19F) – 0–50kg / Standard Touring
• Front Heavy-Duty Raised Coil Springs (RC-JPL19F-HD) – 50–100kg / Steel Bumper & Winch — mandatory to eliminate nose-dive under heavy steel bumpers
• Rear Nitro Max Shock Absorbers – Pair (NM-JT20R) – matched rear damping for five-link rear coil configuration
• Rear Heavy-Duty Coil Springs (RC-JPJT20R) – 0–150kg / Everyday Touring
• Rear Extra Heavy-Duty Coil Springs (RC-JPJT20R-HD) – Constant 350kg+ for permanent canvas tents, steel canopies & drawer slides
• Heavy-Duty Steering Damper Upgrade (RAW-SD-5011) – strongly recommended (see note below)

⚠️ Recommended Installation Accessories

The Gladiator JT’s exceptionally long wheelbase places unique structural leverage on the rear axle under loaded trail driving, and its solid front axle is sensitive to post-lift steering geometry changes. We strongly recommend adding the following to your order:

• Heavy-Duty Steering Stabilizer (RAW-SD-5011) – eliminates front-end bump-steer and high-speed wheel wobble on rough dirt tracks

Technical Specifications

• Total Lift: 50mm (2 inches) over factory ride height
• Kit Weight: ~36–41kg (slightly heavier than standard Wrangler kits due to beefier rear progressive spring windings for cargo carrying)
• Packaged Dimensions: 880mm × 460mm × 290mm
• Shock Bore: 45mm (Nitro Max) | Outer Tube: 61mm steel | Sealing: Multi-lip HNBR high-temperature

Warranty

Industry-leading 3-Year / 60,000km Warranty — covers progressive coil sagging, manufacturing fracturing, and high-pressure oil seal blowouts under extreme trail conditions.

Professional Fitment Available Nationwide

Prefer to have it fitted by experts? Advanced 4x4 offers professional fitment at our fitment centres across South Africa. Simply place your order online and contact us to book your fitment appointment at the centre nearest to you. Our trained technicians will ensure your suspension kit is installed correctly for optimal performance and safety.

Selecting the Right Configuration

To ensure you receive the correct spring rate for your build, please specify your setup at checkout:

• Front-end weight: Standard Touring / Steel Bumper & Winch
• Rear-end setup: Everyday Touring (0–150kg) / Permanent 350kg+ Overland Build (RTT, steel canopy, drawers & camp gear)

⏳ Lead Time: Please allow 14 business days for production/sourcing if stock is not immediately available.
