Victron MultiPlus 12/800/35-16 230V Inverter/Charger

Victron MultiPlus 12/800/35-16 230V — Inverter, Charger & UPS in One

The Victron MultiPlus 12/800/35-16 is a powerful combination inverter, battery charger, and UPS in a single compact unit. With 800VA continuous inverter output, a 35A battery charger, and a 16A AC transfer switch, it delivers uninterrupted power for off-grid, backup, marine, and overlanding applications — with remote monitoring via the free Victron VRM portal.

Key Features:

• UPS Function — <20ms Switchover: In the event of grid or shore power failure, the inverter activates in under 20 milliseconds — computers and sensitive electronics continue operating without interruption.
• Power Assist: When shore or generator power is insufficient for peak loads, the MultiPlus instantly supplements from the battery — then recharges when load reduces.
• Power Control: Set a maximum input current limit to prevent overloading your generator or shore supply — the unit uses any spare capacity for charging.
• 35A Smart Battery Charger: Built-in multi-stage adaptive charger with temperature compensation — charges and maintains your battery bank efficiently.
• Remote Monitoring via VRM Portal: Monitor and control your system locally (LAN) or remotely via the free VRM app and portal from any phone, tablet, or PC.
• Search Mode: Reduces no-load power consumption by approximately 70% — switches on every 2 seconds to detect load, then stays on if load exceeds the set threshold.
• Programmable Relay: Configurable as an alarm relay for pre-alarm conditions (overheating, high ripple, low battery voltage).
• Proven Toroidal Transformer Design: Full bridge topology with toroidal transformer — short circuit proof and protected against overheating from overload or high ambient temperature.

Specifications:

• Brand: Victron Energy
• Model: MultiPlus 12/800/35-16
• Input Voltage: 12V DC
• AC Output: 800VA / 230V
• Charger Output: 35A
• AC Transfer Switch: 16A
• UPS Switchover Time: <20ms
• Communication: VE.Bus
• Remote Monitoring: VRM Portal (free)
• Dimensions: 360mm (H) x 240mm (W) x 100mm (D)
• Weight: 6.4kg

What's in the Box:

• 1x Victron MultiPlus 12/800/35-16 230V VE.Bus

⏳ Lead Time: Please allow 14 business days for sourcing if stock is not immediately available.
