Quick Pitch RTT Rooftop Tent – Rivet-Less Hard-Shell Aluminium Clamshell for 2 Adults

No Rivets. No Leaks. No Compromises. The Benchmark Hard-Shell RTT.

Traditional rooftop tents rely on hundreds of pop rivets or mechanical bolts that slowly loosen under harsh trail vibrations — tearing canvas and creating water leaks. The Quick Pitch RTT Rooftop Tent eliminates this vulnerability entirely with a 100% rivet-less, extruded aluminium hard shell. Instead of failure-prone standard bracket hinges, it features interlocking aluminium swivel extrusion profiles that distribute the weight of the upper shell evenly across the entire width of the chassis.

Undo the heavy-duty stainless steel travel latches and high-pressure gas struts lift the shell open automatically in seconds. The signature all-side wrap-around flysheet does the rest.

🎙️ Key Features

• 100% Rivet-Less Extruded Aluminium Shell: Structurally bonded aluminium extrusion chassis with no bolts or pop rivets — eliminates all leak paths and mechanical loosening under harsh trail vibrations
• Extrusion Swivel Hinge System: Interlocking aluminium swivel profiles replace failure-prone bracket hinges — distributes upper shell weight evenly across the full chassis width, preventing dust and water entry
• All-Side Wrap-Around Flysheet: Continuous zip-out canvas awning extends on all sides — blocks rain and morning dew from dripping into entry portals while creating a thermal shade barrier to lower cabin temperatures
• Outer Midge Net with Dual Canvas Control: Outer-mounted midge net allows full ventilation while the internal canvas can be independently opened or closed — the best of both worlds in any climate
• Full-Length Side Utility Rail: Integrated full-length side-mounted utility rail for mounting accessories, lights, or gear directly to the tent exterior
• 40kg Lid Cargo Rating: Upper shell supports a maximum permanent dynamic load of 40kg while driving or opening via integrated dual luggage rails
• Integrated Power Hub: Factory pre-wired with 1 x 12V socket, 2 x USB ports (including 1 x USB-C), and a roof-mounted LED light matrix with accessible toggle switch — through weatherproof body inlets
• Dual Climate Insulation: High-density thermal insulation composite in the roof lining + additional insulation layer under the mattress — regulates temperature in freezing winter camps and blistering summer heat
• 75mm High-Density Foam Mattress: Full 2,100mm x 1,350mm sleeping surface for 2 adults
• Complete Gear Management: 6 x internal storage bags, ceiling-mounted gear net, exterior quick-clip shoe bag (mounts either side), and internal bungee cord system for canvas closure
• Anti-Slip Ladder System: 2.6m telescopic aluminium ladder locks into structural anti-slip safety receiving brackets — eliminates kick-outs on muddy or slick ground

📐 Technical Specifications

• SKU: QPSA-RTT
• Weight: 84.0 kg
• Closed Dimensions: 2,300 mm (L) x 1,450 mm (W) x 290 mm (H)
• Open Internal Apex: 2,100 mm (L) x 1,350 mm (W) x 1,450 mm (H)
• Mattress: 2,100 mm (L) x 1,350 mm (W) x 75 mm (H) high-density foam
• Capacity: 2 adults
• Lid Load Rating: 40 kg maximum dynamic load via dual luggage rails
• Shell: Rivet-less extruded structural aluminium, matte black textured powder coat
• Hinge: Interlocking aluminium swivel extrusion profiles
• Power: 1 x 12V socket, 2 x USB ports (incl. 1 x USB-C), LED roof light with toggle switch
• Ladder: 2.6m telescopic aluminium with anti-slip safety bracket
• Storage: 6 x internal bags, gear net, shoe bag, bungee cord system
• Ventilation: Outer midge net + independent internal canvas control

⚠️ Installation Notice

At 84kg, this tent requires the Quick Pitch Tent Mount Bracket Set combined with high-tensile tracking bolts to secure the under-extrusion to load bars safely. Pair with Quick Pitch Load Bars for a complete, structurally rated roof mounting system.

💡 Complete Your Overland Build

Add the Quick Pitch RTT Trax-Mount Pair to carry MaxTrax on the tent lid, mount the Quick Pitch Quick-en-Suite Box Unit on the opposite side for a complete bush bathroom, and pair with the Quick Pitch 270° Weathershade Awning for a fully integrated sleeping, recovery, and shade setup.

✅ Why Quick Pitch?

Protected under the official Quick Pitch South Africa Manufacturer Guarantee — covering rivet-less aluminium fractures, gas-strut failure, and canvas track degradation under harsh trail conditions. The benchmark hard-shell RTT — trusted by overlanders globally for its engineering precision and zero-leak construction.

🔩 Fitment & Installation

Professional fitment available at Advanced 4x4 or any of our authorised fitment centres nationwide. Our team verifies your vehicle's roof load rating, configures the correct bracket and load bar setup, and ensures safe torque settings for an 84kg static payload.

⏳ Lead Time

Please allow 14 business days for production/sourcing if stock is not immediately available.
