Quick Pitch Weathershade 270° 2M Awning – Compact Legless Freestanding 4x4 Canopy (11.5m²)

11.5m² of Shade. Zero Poles. Built for Short-Wheelbase Rigs.

Standard 2.5m awnings are too long for compact SUVs, double-cab bakkie cabs, and smaller canopy frames — creating ugly overhangs and catching wind. The Quick Pitch Weathershade 270° 2M Awning solves this by shrinking the closed bag length to exactly 2 metres, saving 500mm of roof real estate while delivering a high-strength 11.5m² freestanding shade footprint that wraps completely around the side and rear of your vehicle — without a single support leg.

Same heavy-duty mechanical foundation as the flagship 2.5m model. Lighter. More compact. Purpose-built for short-wheelbase vehicles.

⚠️ Important: Select your deployment side (LHS or RHS) and whether you want the awning only or bundled with the 2M Side Wall Kit.

🌳 Key Features

• Compact 2m Bag Length: Saves 500mm of roof rail space vs the standard 2.5m model — purpose-built for short-wheelbase 4x4s, compact SUVs, and smaller canopy frames
• 11.5m² Freestanding Shade: 2.0m arm travel radius wraps completely around the side and rear of your vehicle for a massive, unobstructed shade footprint
• 5 Legless Extruded Arms: The only awning with 5 purposefully legless extruded aluminium arms — withstands severe crosswinds without flimsy support poles or ground guy ropes
• 6mm Structural Stainless Steel Hinges: Twin double-action hinges laser-cut and CNC-bent from 6mm structural stainless steel to bear the twisting leverage of the moving arms
• Gusseted Box Arms: Internal structural webbing gussets on all arms resist upward wind lift and trail twist
• Aluminised Heat-Reflective Canvas: High-performance water-resistant overlanding canvas with aluminised inner lining for full thermal UV deflection — keeps the shade zone noticeably cooler
• Integrated Harsh Weather Pole: 1 x fold-out anchor pole with tie-down strap tucked neatly inside the arm channels — no loose hardware to lose on the trail
• 2M Side Wall Kit Compatible: Available bundled with the Quick Pitch 2M Side Wall Kit (350mm PVC mud skirt, midge-proof mesh) to convert your canopy into a fully enclosed camp room

📐 Technical Specifications

• SKU: QPSA-WS270-2M
• Packed Dimensions: 2,000 mm (L) x 155 mm (W) x 150 mm (H)
• Arm Length: 2.0 m per arm
• Shade Coverage: ~11.5 m²
• Weight: ~20.5 kg
• Arms: 5 x legless extruded aluminium arms with internal gusset reinforcement
• Hinges: 6mm structural stainless steel, laser-cut and CNC-bent (twin double-action design)
• Canvas: Water-resistant, UV-deflecting overlanding canvas with aluminised heat-reflective lining
• Included: 1 x anchor pole + tie-down strap (stored inside arm channels), canvas travel bag
• Side Wall Option: Available with Quick Pitch 2M Side Wall Kit (combo price: R25,499)

💡 Complete Your Compact Overland Setup

Pair this awning with the correct mounting bracket for your setup — Quick Pitch Awning to Front Runner Bracket Set, Awning to Tent Bracket for a rackless RTT configuration, or Awning to Load Bar Bracket Set. Add the 2M Side Wall Kit for a fully enclosed, weatherproof camp room.

✅ Why Quick Pitch?

Backed by the Quick Pitch South Africa Lifetime Mechanical Guarantee on the structural 6mm stainless steel hinge mechanism. The compact solution for overlanders who refuse to compromise on shade coverage just because their wheelbase is shorter.

🔩 Fitment & Installation

Professional fitment available at Advanced 4x4 or any of our authorised fitment centres nationwide. Our team confirms the correct bracket set for your specific rack system and vehicle orientation.

⏳ Lead Time

Please allow 14 business days for production/sourcing if stock is not immediately available.
