Quick Pitch Weathershade Maxx 270° Awning – Legless Freestanding 4x4 Canopy (17m² Shade)

17 Square Metres of Shade. Zero Poles. The Biggest Quick Pitch Awning Ever Built.

Standard 4x4 awnings fall short on coverage for large utility trucks, long-wheelbase canopies, and off-road caravans. The Quick Pitch Weathershade Maxx 270° Awning solves this entirely — stretching the articulated box arms to a massive 2.7 metres to deliver an industry-leading 17m² of freestanding shade that wraps completely around the side and rear of your vehicle, without a single support leg in sight.

Built on the same heavy-duty mechanical foundation as the standard 270° model, but scaled up for the demands of large rigs, commercial canopies, and serious basecamp setups.

⚠️ Important: Select your deployment side — Left-Hand Side (QPSA-AW-MAXX-LHS) or Right-Hand Side (QPSA-AW-MAXX-RHS). Due to the 2.7m closed bag length, this awning requires a long mounting surface — ideal for large 4x4 trucks, long-wheelbase canopies, trailers, or caravans.

🌳 Key Features

• 17m² Freestanding Shade Coverage: 2.7m arm travel radius wraps completely around the side and rear of your vehicle — the largest shade footprint in the Quick Pitch lineup
• Legless Freestanding Design: Deploys without support poles or guy ropes — the rigid arm structure withstands extreme crosswinds without failure-prone legs
• 6mm Structural Stainless Steel Hinges: Twin double-action hinges laser-cut and CNC-bent from 6mm structural stainless steel to bear the immense rotational leverage of the 2.7m arms — the only awning in its class with this specification
• Gusseted Extruded Box Arms: Reinforced with internal structural webbing gussets to resist twisting and upward lifting leverage under unexpected wind gusts
• Heat-Reflective Canvas: High-performance water-resistant overlanding canvas with a silver inner lining for full thermal UV deflection — keeps the shade zone noticeably cooler on hot sunny days
• Harsh Weather Kit Included: Two fold-out anchor poles with 6 tie-down straps for extreme wind conditions, plus additional tent pegs and tie-down straps for each arm
• Maxx Side Wall Kit Compatible: Pairs directly with the Quick Pitch Weathershade Awning Maxx Side Wall Kit (5-panel ripstop enclosure) to convert your canopy into a fully enclosed, weatherproof camp room
• Universal Vehicle Fitment: Mounts to any large vehicle, trailer, or caravan via Quick Pitch bracket systems

📐 Technical Specifications

• SKU: QPSA-AW-MAXX-LHS (Left-Hand Side) | QPSA-AW-MAXX-RHS (Right-Hand Side)
• Packed Dimensions: 2,700 mm (L) x 155 mm (W) x 150 mm (H)
• Arm Length: 2.7 m per arm
• Shade Coverage: 17.0 m²
• Weight: ~29.0 – 31.0 kg
• Hinges: 6mm structural stainless steel, laser-cut and CNC-bent (twin double-action design)
• Arms: Extruded aluminium with internal gusset reinforcement
• Canvas: Water-resistant, UV-deflecting overlanding canvas with silver heat-reflective lining
• Included: 2 x anchor poles, 6 x tie-down straps, tent pegs, canvas travel bag
• Side Wall Option: Compatible with Quick Pitch Weathershade Maxx Side Wall Kit (5 ripstop panels)

💡 Complete Your Basecamp Setup

Pair this awning with the correct mounting bracket for your rack system — Quick Pitch Awning to Front Runner Bracket Set, Awning to Rhino-Rack Pioneer Bracket Set, or Awning to Load Bar Bracket Set. Add the Quick Pitch Weathershade Awning Maxx Side Wall Kit to convert your massive canopy into a fully enclosed, weatherproof basecamp room.

✅ Why Quick Pitch?

Backed by the Quick Pitch South Africa Lifetime Mechanical Guarantee on the structural stainless steel hinge assembly and aluminium tracking layout. The biggest, most capable awning Quick Pitch has ever built — engineered for overlanders who refuse to compromise on basecamp comfort.

🔩 Fitment & Installation

Professional fitment available at Advanced 4x4 or any of our authorised fitment centres nationwide. Our team confirms the correct bracket set for your specific rack system, vehicle length, and orientation.

⏳ Lead Time

Please allow 14 business days for production/sourcing — often manufactured to order due to its specialised size.
